	Ссылка №	Артикул	Наименование	Цена
	1-1	02050030124	magneto stater	1 138 руб.
	1-2	02050030032	magneto rotor	1 077 руб.
	1-3	02050020014	carburetor	1 844 руб.
	1-4	03130010013	spark plug
	1-5	02060050026	cylinder	2 031 руб.
	1-6	02070010032	sealing washer	84 руб.
	1-7	03040020019	spring washer
	1-8	03050010014	spring washer
	1-9	03010010061	scrow
	1-10	02070010019	cylinder side washer	82 руб.
	1-11	70030020016	inlet mag	385 руб.
	1-12	02070010071	Carburetor side washer	30 руб.
	1-13	03020020052	screw assem
	1-14	026116000	muffler	390 руб.
	1-15	03010010051	screw assem	49 руб.
	1-16	02070010162	muffler washer	179 руб.
	1-17	70030030164	plate
	1-18	03020020032	screw
	1-19	03060010002	orientation pin
	1-20	02020130001	cluch step screw
	1-21	03040050042	cluch washer	11 руб.
	1-22	026145100	clutch shoe comp	384 руб.
	1-23	70070080018	cluch shoe seat	136 руб.
	1-24	03040050052	plat washer
	1-25	03010010010	Screw
	1-26	70070050107	front half crankcase	709 руб.
	1-27	70070050023	rear half crankcase	909 руб.
	1-28	02070010119	crankcase gasket	53 руб.
	1-29	03100010032	oil seal	55 руб.
	1-30	03090010028	bearing	190 руб.
	1-31	03070010001	half-moon bon	51 руб.
	1-32	02020020003	piston ring	118 руб.
	1-33	026121100	piston	557 руб.
	1-34	03090020018	needle bearing	120 руб.
	1-35	02020010004	piston pin
	1-36	02020150002	stop washer
	1-37	02020030017	piston pin circlip	30 руб.
	1-38	02020120054	crank shaft comp(levototation)	1 294 руб.
	1-39	02050100012	start pulley assem(levorotation)	155 руб.
	1-40	02050070016	startter assem(levorotation)	735 руб.
	1-41	03020020043	screw assem
	1-42	02090010011	cleaner element	126 руб.
	1-43	70030040123	cleaner outside cover	319 руб.
	1-44	02110030079	knob	72 руб.
	1-45	02110020026	oil bop nib	177 руб.
	1-46	70050030079	oil lid	454 руб.
	1-47	03040010009	spring washer
	1-48	03020020051	screw
	1-49	03020010013	screw
	1-50	02050120002	filter	114 руб.
	1-51	02080030025	oil box rubber stopple	72 руб.
	1-52	03020020028	screw
	1-53	02080020012	stationary bushing
	1-54	02050050144	stop switch assy
	1-55	70030030695	cylinder cover	364 руб.
	1-56	80010020080	fan cover	540 руб.
	1-57	03010110007	screw
	1-58	03040010008	spring washer
	1-59	70080120007	cleaner inside cover	128 руб.
	1-60	03020020054	screw
	1-61	02070010048	gasket
	1-62	02110030050	plastic gasket
